OnLogic 8th Generation Intel Core High-Performance Compact Rugged Computer DX-1100

COMPACT POWERHOUSE

Powered by the Intel® C246 chipset, the DX-1100 features 8th generation processors from Core™ i3 to i7, letting you scale the level of performance to your application. Supporting up to 64 GB of DDR4 memory, the DX-1100 is a rugged powerhouse that tackles heavy multitasking while driving up to three independent displays. For remote installations or network redundancy, the DX-1100 is available with 4G LTE connectivity.

RUGGED RELIABILITY

The DX-1100 is a rugged and compact workstation ready for the toughest environments. With its extruded aluminum fanless design the DX-1100 is protected from dust, debris, chemical, and moisture ingress, increasing the reliability and lifespan of the system. With high shock and vibration tolerances, a wide operating temperature (based on processor), and a wide input voltage of 9 ~ 48 V, the DX-1100 thrives in challenging applications. Combined with flexible mounting options, the DX-1100 is a high-performance rugged computer that withstands the rigors of industrial environments no matter where you put it.

INDUSTRY LEADING VERSATILITY

With six USB 3.0, four COM, dual Gb LAN, and dual USB 3.1 ports, the DX-1100 easily integrates into a range of applications. Cincoze Combined Multiple I/O (CMI) modules allow for further I/O customization with options for RJ45/M12 Gb LAN, additional COM and DIO, while a Control Function Module provides power ignition sensing or PoE functionality. The DX-1100 takes functionality even further with dual 2.5” hot-swap bays and three full-height mPCIe/mSATA slots for wireless, I/O, or high-speed storage drive. The system can also drive triple independent displays with DisplayPort, HDMI, and DVI-I ports that support a wide range of connectors.
