Moxa Ethernet extender IEX-402-VDSL2-T
Part Number: IEX-402-VDSL2-T
Features and Benefits
Automatic CO/CPE negotiation reduces configuration time
Link Fault Pass-Through (LFPT) support and interoperable with Turbo Ring and Turbo Chain
LED indicators to simplify troubleshooting
Easy network management by web browser, Telnet/serial console, Windows utility, ABC-01, and MXview
The IEX-402 is an entry-level industrial managed Ethernet extender designed with one 10/100BaseT(X) and one DSL port. The Ethernet extender provides a point-to-point extension over twisted copper wires based on the G.SHDSL or VDSL2 standard. The device supports data rates of up to 15.3 Mbps and a long transmission distance of up to 8 km for G.SHDSL connection; for VDSL2 connections, the data rate supports up to 100 Mbps and a long transmission distance of up to 3 km.
The IEX-402 Series is designed for use in harsh environments. The DIN-rail mount, wide operating temperature range (-40 to 75°C), and dual power inputs make it ideal for installation in industrial applications.
To simplify configuration, the IEX-402 uses CO/CPE auto-negotiation. By factory default, the device will automatically assign CPE status to one of each pair of IEX devices. In addition, Link Fault Pass-through (LFP) and network redundancy interoperability enhance the reliability and accessibility of communication networks. In addition, advanced managed and monitored functionality through MXview, including a virtual panel, improve the user experience for quick troubleshooting.
Ethernet Interface
10/100BaseT(X) Ports (RJ45 connector)
1
Auto negotiation speed
Full/Half duplex mode
Auto MDI/MDI-X connection
Combo Port, RJ-11 (RJ45 connector) or Detachable 2-Contact Terminal Block
1
Standards
ITU G.993.2 for very high speed digital subscriber line transceivers 2
Ethernet Software Features
Management
SNMPv1/v2c/v3, Modbus TCP, Back Pressure Flow Control, DHCP Client, HTTP, LLDP, Syslog, Telnet, TFTP
MIB
MIB-II
Time Management
SNTP
