Moxa Industrial Gigabit Managed Ethernet Switch with 7 10/100BaseT(X) ports, 1 10/100/1000BaseT(X) and 2 SFP (mini-GBIC) ports, 0 to 60°C.
Part Number: EDS-510A-1GT2SFP
*Note: This Item is Non-Returnable
Features and Benefits
• Turbo Ring and Turbo Chain (recovery time < 20 ms @ 250 switches), and
RSTP/STP for network redundancy
• IGMP Snooping, QoS, IEEE 802.1Q VLAN, and port-based VLAN supported
• Easy network management by web browser, CLI, Telnet/serial console,
Windows utility, and ABC-01
• PROFINET or EtherNet/IP enabled by default (PN or EIP models)
• Supports MXstudio for easy, visualized industrial network management
Input/Output Interface
Alarm Contact Channels
2, Relay output with current carrying capacity of 1 A @ 24 VDC
Digital Input Channels
2
Digital Inputs
+13 to +30 V for state 1
-30 to +3 V for state 0
Max. input current: 8 mA
Ethernet Interface
10/100BaseT(X) Ports (RJ45 connector)
7
Auto negotiation speed
Full/Half duplex mode
Auto MDI/MDI-X connection
10/100/1000BaseT(X) Ports (RJ45 connector)
1
Auto negotiation speed
Full/Half duplex mode
Auto MDI/MDI-X connection
1000BaseSFP Slots
2
Standards
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X) and 100BaseFX
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3z for 1000BaseSX/LX/LHX/ZX
IEEE 802.1X for authentication
IEEE 802.1D-2004 for Spanning Tree Protocol
IEEE 802.1w for Rapid Spanning Tree Protocol
IEEE 802.1s for Multiple Spanning Tree Protocol
IEEE 802.1Q for VLAN Tagging
IEEE 802.1p for Class of Service
IEEE 802.3x for flow control
IEEE 802.3ad for Port Trunk with LACP
