Aruba 2930F Series Switches

Aruba 2930F Series Switches

Part Number: See below

The Aruba 2930F Switch Series is designed for customers creating digital workplaces that are optimized for mobile users with an integrated wired and wireless approach. These Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like Aruba ClearPass Policy Manager and Aruba AirWave. Stacking with Virtual Switching Framework (VSF) provides simplicity and scalability. The 2930F supports built-in 1GbE or 10GbE uplinks, PoE+, Access OSPF routing, Dynamic Segmentation, robust QoS, RIP routing, and IPv6 with no software licensing required.

Key Features

• 8 or 24 or 48, Auto sensing 10/100/1000 BaseT or Auto sensing 10/100/1000 PoE+ Ports
• 4 SFP+ 1/10GbE ports; PHY-less
• 1 dual-personality (RJ-45 or USB micro-B) serial console port
• Weight, 2.0-5.0 kg
• Form Factor: (1U height)
• Memory: , 1 GB DDR3 SDRAM; Packet buffer size: 12.38 MB 4.5MB Ingress/ 7.875MB Egress, 4 GB eMMC
• Processor: Dual Core ARM® Coretex A9 @ 1016 MHz

A powerful Aruba ProVision ASIC delivers performance, robust feature support and value with programmability for the latest applications. Stacking with Virtual Switching Framework (VSF) provides simplicity and scalability. The 2930F supports built-in 1GbE or 10GbE uplinks, PoE+, Access OSPF routing, Dynamic Segmentation, robust QoS, RIP routing, and IPv6 with no software licensing required.

The Aruba 2930F Switch Series provides a convenient and cost-effective access switch solution that can be quickly set up with Zero Touch Provisioning. The robust Layer 3 feature set includes a limited lifetime warranty.

Simplicity built-in

This cost-effective, agile switch provides fast, powerful network access to IoT devices, access points, and users. Featuring convenient built-in uplinks and PoE+ power, the 2930F is simple to deploy and manage with advanced security and network management tools.

Security for users and IoT

Aruba Dynamic Segmentation extends Aruba’s foundational, wireless role-based policy capability to Aruba wired switches. That means regardless of how users and IoT devices connect, consistent policies are enforced across wired and wireless networks, keeping traffic secure and separate.

Unified cloud-based management

Aruba Central delivers full-service AI insights, and security and unified infrastructure management for campus, branch, remote, and data center networks, all from a single pane of glass. It’s network configuration and operations made simple.

Simple deployment

With Zero-Touch Provisioning (ZTP) and support from cloud-based Aruba Central, you can quickly set up remote offices with little or no IT support.

Secure and powerful access
Optimized for mobile users with an integrated wired and wireless approach, these reliable Layer 3 switches are easy to deploy and manage.

Layer 3 Ethernet switches
Comes with enterprise-grade feature set that includes static and RIP routing, IPv6, ACLs, robust security, and QoS.

Grow quickly and simply
Supports 8-member VSF stacking so you can quickly add users and devices while keeping switch management simple.

Right-size switches
Choose from compact 8-, 12-, 24-, and 48-port Ethernet switches with optional PoE and 10GbE uplinks built-in.

Power over Ethernet
Up to 740W of PoE to support access points, IP phones, and IoT.

Flexible management
Innovative design supports cloud-based and on-premise management, CLI, and easy-to-use Web GUI with the same hardware, eliminating rip and replace of equipment as network management needs grow.

Models Available:
